Устройство защитного отключения Eaton (Moeller) CFI6-63/2/05-A-DE, 2 полюса, тип а, 63а, 500ма

235775
5 549.00 ₽
Нет в наличии
10 дн.
Отложить
ООО "АльфаИнжиниринг" ИНН 7751019223
+7(926)321-11-22
Задать вопрос
Доставка
Варианты оплаты
БрендEaton СтранаСША

Технические характеристики

Артикул235775
Объем, дм30,204
Масса, кг0,22

Design verification as per IEC/EN 61439

Technical data for design verification
Rated operational current for specified heat dissipation InA63
Heat dissipation per pole, current-dependent sub>,vidW0
Equipment heat dissipation, current-dependent sub>,vidW7.2
Static heat dissipation, non-current-dependent sub>,vsW0
Heat dissipation capacity sub>,dissW0
Operating ambient temperature min. °C-25
Operating ambient temperature max. °C55
Starting at 40 °C, the max. permissible continuous current decreases by 3% for every 1 °C
IEC/EN 61439 design verification
10.2 Strength of materials and parts
10.2.2 Corrosion resistance Meets the product standard's requirements.
10.2.3.1 Verification of thermal stability of enclosures Meets the product standard's requirements.
10.2.3.2 Verification of resistance of insulating materials to normal heat Meets the product standard's requirements.
10.2.3.3 Verification of resistance of insulating materials to abnormal heat and fire due to internal electric effects Meets the product standard's requirements.
10.2.4 Resistance to ultra-violet (UV) radiation Meets the product standard's requirements.
10.2.5 Lifting Does not apply, since the entire switchgear needs to be evaluated.
10.2.6 Mechanical impact Does not apply, since the entire switchgear needs to be evaluated.
10.2.7 Inscriptions Meets the product standard's requirements.
10.3 Degree of protection of ASSEMBLIES Does not apply, since the entire switchgear needs to be evaluated.
10.4 Clearances and creepage distances Meets the product standard's requirements.
10.5 Protection against electric shock Does not apply, since the entire switchgear needs to be evaluated.
10.6 Incorporation of switching devices and components Does not apply, since the entire switchgear needs to be evaluated.
10.7 Internal electrical circuits and connections Is the panel builder's responsibility.
10.8 Connections for external conductors Is the panel builder's responsibility.
10.9 Insulation properties
10.9.2 Power-frequency electric strength Is the panel builder's responsibility.
10.9.3 Impulse withstand voltage Is the panel builder's responsibility.
10.9.4 Testing of enclosures made of insulating material Is the panel builder's responsibility.
10.10 Temperature rise
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.12 Electromagnetic compatibility Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.13 Mechanical function The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.

Technical data ETIM 6.0

Circuit breakers and fuses (EG000020) / Residual current circuit breaker (RCCB) (EC000003)
Electric engineering, automation, process control engineering / Electrical installation, device / Residual current protection system / Residual current circuit breaker (RCCB) (ecl@ss8.1-27-14-22-01 [AAB906011])
Number of poles 2
Nominal rated voltage V230
Nominal rated current A63
Rated fault current A0.5
Mounting method DIN rail
Leakage current type A
Selective protection No
Short-circuit breaking capacity (Icw) kA6
Surge current capacity kA0.25
Frequency 50 Hz
Additional equipment possible Yes
Degree of protection (IP) IP20
Construction size (in accordance with DIN 43880) 1
Width in number of modular spacings 2
Built-in depth mm69.5
Short-time delayed tripping No


Тип
  • узо
Объем дм3
0,2 дм3
Ток, А
63 А
Количество полюсов
  • 2
Модель
CFI6-63/2/05-A-DE
Бренд
Eaton
Вес
0,22 кг
Производитель
Eaton (Moeller)
Страна
США
